MG 300W 24/36V Power Supply
300W DC Power Supply with Dual Output
The MineGlow 300W DC Power Supply (Driver) is a reliable, rugged power supply, engineered specifically for energising the x-Glo LED Strip Lights in demanding industrial environments.
Encased in a water-resistant IP67-rated aluminium enclosure, the MG 300W PSU features dual output capability, making it ideal for powering multiple lighting from a single unit. Whether you’re lighting up a mining tunnel, rail corridor, or underground workshop, this power supply delivers consistent, efficient power with minimal maintenance.
It is available in 24vDC or 36VDC. A 36VDC Potted power supply version is available too.
Recommended for use with our x-Glo Standard LED Strip lights for:
- Mining tunnels, conveyor tunnels, drifts, and declines
- Underground stores
- Cuddies and crib rooms
- Dump points
- Train loadout areas
- Workshops & maintenance bays
- Any industrial application requiring 36v power
Fully certified for use in Australia. All certifications available on request.
Go to the Downloads section below for full technical specifications.
SPECIFICATIONS | SUMMARY
| Table Header | Table Header |
|---|---|
| Part Number | 300W-24v-DO 300W-36v-DO |
| Power | 300W Single or Dual Output |
| Power Supply | Unpotted - Sealed enclosure with a single input cable and dual output cable – 1m 36V Potted Option available |
| Voltage INPUT | 110 - 265VAC Single Phase |
| Voltage OUTPUT | 24 or 36VDC |
| Current - INPUT | 3A @ 110VAC (Max) |
| Current - OUTPUT | 24V – 12.5A 36v - 8.3A |
| Enclosure Type | Ruggedised Aluminium casing |
| Enclosure Size | 258L x 75W x 48H |
| Operating Temperature | -25°C to 50°C |
| IP Rating | IP67 |
| External Isolator | N/A |
| Circuit Breaker | N/A |
| Warranty | 12 Months |
| Maximum Run Length with 300W Powered from one end.
The distance doubles when powered with 300w from both ends | |
| x-Glo Standard Range – 24V 24-24v DC 36-24v DC 1000-72-24v DC | 56m 37m 22m |
| x-Glo Standard Range – 36V
24-36v DC 650-44-36v DC 1000-66-36v-DC | 75m 49m 30m |
